Pigment Orange PO13 - Bright Orange for Inks, Paints, and Coatings

Pigment Orange PO13 delivers uncompromised brilliance and durability for premium coatings, inks, and industrial finishes. As a benzimidazolone-based organic pigment, it combines intense reddish-orange hues (CIE Lab*: L* 52±2, a* 48±1, b* 65±2) with exceptional lightfastness and chemical resistance. Engineered for automotive refinish systems, architectural coatings, and packaging inks, PO13 outperforms conventional oranges in chromatic purity and processing stability.

‌Core Performance Advantages‌

‌Color Intensity & Consistency‌

• 98% chroma retention after 1:50 TiO₂ reduction (ISO 787-24)
• Metamerism index <0.6 across D50/D65/F11 illuminants (ISO 3668)
• Batch-to-batch ΔE <0.4 (CIEDE2000 formula)

‌Superior Durability‌

• ΔE <2.0 after 2,000 hrs QUV-A exposure (ASTM G154 Cycle 4)
• Chemical resistance: Grade 5 in ASTM D1308 acid/alkali tests
• Thermal stability up to 220°C (DIN 53775 TGA analysis)

‌Processing Versatility‌

• Achieves Hegman 7 fineness in 20-minute dispersion (ASTM D1210)
• <5% viscosity increase at 15% pigment loading (ASTM D2196)
• Anti-flocculation performance in waterborne polyurethanes

‌Application Excellence‌

‌Automotive OEM/Refinish‌

• Matches RAL 2008/2009 standards in 1K/2K systems
• Maintains 90° gloss in acrylic melamine clearcoats
• Passes GM 9540P cyclic corrosion resistance

‌Architectural Coatings‌

• Exceeds 15-year color retention (ISO 2810 Q-SUN B02)
• 97% UV absorption (350–400 nm) for exterior facades
• Zero chalking in elastomeric roof coatings (ASTM D4214)

‌Packaging Inks‌

• FDA 21 CFR 175.300 compliance for food-contact substrates
• ≤0.1% rub-off in alcohol-based flexographic inks (IGT Testing)
• <30-second drying time in UV-curable offset systems

‌Industrial Coatings‌

• Withstands 1,000 hrs salt spray in epoxy primers (ASTM B117)
• Non-bleeding in coil coatings (PV 1303 cyclic humidity test)
• Maintains conductivity <10⁸ Ω/sq in ESD-safe formulations

‌Technical Specifications‌

• ‌Color Index‌: C.I. Pigment Orange 13
• ‌CAS No.‌: 3520-72-7
• ‌Chemical Class‌: Benzimidazolone
• ‌Density‌: 1.45–1.55 g/cm³ (ISO 787-10)
• ‌Oil Absorption‌: 40–45 g/100g (ISO 787-5)
• ‌Particle Size‌: 0.1–0.3 μm (SEM analysis)
• ‌pH Value‌: 6.8–7.5 (ISO 787-9)

‌Formulation Guidelines‌

‌Waterborne Coatings‌

• Pre-disperse with 12% acrylic dispersant (35% solids)
• Mill using 0.4 mm ZrO₂ beads to Hegman 7+
• Stabilize with 0.3% HEUR thickener

‌Solvent-Borne Inks‌

• Optimal loading: 18–22% in nitrocellulose systems
• Use 1.5% polyamide anti-settling agent
• Achieve ≤15 μm grind in 3-roll milling

‌Powder Coatings‌

• Premix with 0.8% flow control agent (TGIC-free)
• Extrude at 90–100°C barrel temperature
• Post-add 0.2% tribo-charging additive

‌Regulatory & Sustainability‌

• REACH/SCIP compliant (PAH-free, SVHC <0.01%)
• ECO PASSPORT by OEKO-TEX® certified
• 25% reduced solvent demand vs. conventional pigments
• ISO 14001-certified manufacturing

‌Packaging & Storage‌

Supplied in 20 kg moisture-resistant kraft bags (<0.3% H₂O content). Bulk orders available in 500 kg FIBCs with UV-blocking liners. Store at 15–30°C (RH <60%); 36-month stability guaranteed via accelerated aging tests.

‌Technical Support‌

• Digital color matching (Pantone®/RAL conversions)
• Dispersion simulations using torque rheometry
• Migration testing per EU 10/2011 for plastics
• Weathering prediction algorithms (Q-Lab software)

Pigment Orange PO13 redefines performance standards for organic orange pigments, offering formulators unprecedented chromatic intensity combined with rigorous durability. Its optimized surface chemistry enables rapid dispersion across solvent/water-based systems while maintaining color fidelity under extreme environmental conditions. For coating specialists seeking vibrant, long-lasting orange solutions that meet both aesthetic and technical demands, PO13 delivers a future-ready pigment platform excelling in decorative and protective applications alike.
